Adjusting knitting machine 4
Advanced adjustments
3. Check whether the needle hook of the front needle dips into the pelerine
spring of the rear needle.
Transfer position
Transfer position
4. If this is not the case: Push back needles and correct racking device.
5. Call up the "Service" menu from the "Main menu".
6. Call up the "Service Racking" window.
Service Racking window
"Service Racking" window
7. Enter the value in the "VPK" line using the slider.
A
Wrong: Needle hook hits the needle shaft
B
Wrong: Needle hook hits the pelerine spring
C
Correct: Needle hook hits exactly the intermediate space "Needle
shaft - Pelerine spring"
Depending on the area of application of the machine the transfer
positio
n may need to be corrected towards "Needle shaft" (position
A).
-1…-8
Correction to the left (1 step = 0.18 – 0.25 mm,
according to the machine gauge)
+1…+8
Correction to the right (1 step = 0.18 – 0.25 mm,
according to the machine gauge)
