Repairing the knitting machine 7
Replacing parts
Removing and mounting car riage part
7.3.12 Removing and mounting carriage part
Removing carriage part
Removing carriage part The carriage part is removed when:
the cams must be replaced (e.g. wide or narro
w coupling of tandem
machines)
a carriage part blocks, e.g. when workin
g butts of the movable parts
(needle, coupling part, intermediate slider, and selection jack) are broken.
This chapter contains information on:
Remove the carriage part to replace the cams [4
09]
Remove the carriage part when the carriage assembly is blocked in the
needle bed [412]
Assembling carriage part and carriage assembly [416]
Remove the carriage part to re place the cams
Remove the carriage part to
replace the cams
Key for calling up Manual interventions window
Key for calling up "Manual interventions" window
1. If a central lubrication is present, swivel it into mounting position.
2. Move the carriage assembly outward u
p to the support surface.
3. Switch off 40 V power
supply.
4. Remove the carriage assembly panelling (1).
Panelling o f carriage assembly
Panelling of carriage assembly
Key
Function
Call up "Manual interventions" window
