Racking
5.5.8 Racking
The racking instructions are valid for one carriage stroke.
Racking correction (machine without additional needle bed)
Further information:
 Table Tools [316]
 Helpers for Input [311]
 File tools [317]
 Overview of the Setup2 Editor
of the CMS [
309]
 Setup Data [303]
 Comparing Setup1 to Setup2 [305]
Explanation Value range
VCI… Racking function VCI1 to VCI50
VK Racking correction by m steps (0-10) Step width: 1/70 of
the needle
distance
Dir Direction of the racking correction
< - to the left
> - to the right
?
- not defined, will be defined on the
machine
VV Racking speed n (1-32), without an
instruction VV=32
V+/- V+ - Overracking, in addition to the
racking specification
positive value: Overracking in racking
direction
negative value: Overracking in opposite
to the racking direction
(n=1-24, step
width: 1/8 of the
needle distance)
Comment Comment ASCII Characters
