Stoll CMS 520 C+ - Remote Control with the VNC Viewer

540
11 Machine Management Tools
Remote control with the software VNC
Remote control with the VNC Viewer
11.3.5 Remote control with the VNC Viewer
1. Start the software VNC Viewer on the computer.
 The "VNC Viewer: Connecting Details" win
dow opens.
VNC Viewer: Connection Details window
"VNC Viewer: Connection Details" window
2. Enter the noted IP address of the machine in the "Server" field.
3. In order to configure the software VNC Viewe
r when needed, click on the
"Options" button.
 The "VNC Viewer Options" window opens.
VNC Viewe r Options w indow, Colou r & Encodi ng tab
"VNC Viewer Options" window, "Colour & Encoding" tab
4. In order that all colors are displayed, activate the "Full (all available
colours)" option on the "Colour & encoding" tab under "Colour level".
5. In order to make a small square visible as the
mouse pointer alternative,
deactivate the "Render cursor locally" check box on the "Misc" tab.
6. To save the option adjustments, click on the "Save" button on the "L
oad /
Save" tab under "Defaults".
7. Click on the "OK" button.
When your network makes the Naming Service available,
instead of the IP address the host name can also be entered.
If another port as 5900 was e
ntered during configuration of the
remote control VNC on the machine, the port must be entered
along with e. g. 172.17.12.54:5903.
You can find continuative instructions for configuration of VNC
in the documentation of VNC.
