Stoll CMS 520 C+ - Displaying File in Pattern Editor

271
Adjusting knitting machine 4
Working with files
Displaying fi le in pattern editor
4.3.4 Displaying file in pattern editor
The selected file from the "Load & save" window is displayed in the "Pattern
editor" window (preview).
Keys for t he Pattern editor w indow
Keys for the "Pattern editor" window
Displaying file in pattern editor:
1. From the "Main menu" call up the "Load & Save" window.
2. Select the file to be viewed in the file list.
3. Tap
the "Display file" key.
4. The "Pattern editor" window is open.
Key Function
Call up the "Load & save" window
"Display file" key
Call up "Pattern editor" window
