426
7 Repairing the knitting machine
Replacing parts
Replacing yarn carrier
7.3.16 Replacing yarn carrier
1. Stop the carriage assembly into the left reversing position.
Screws of the yarn carrier limiter
Screws of the yarn carrier limiter
2. Loosen the screws (1) of the yarn carrier limiter.
3. To remove the yarn carrier limiters, turn the s
crews (1). The yarn carrier
limiters can be removed and mounted in any position.
4. Shift yarn carrier to the right or left to the replacement point (A) and
remove
it.
5. Place new yarn carriers on the rails.
6. Place the yarn carrier limiters of yarn carriers on the rails,
positi
on them in
a staggered way and screw them on tight.
7. Check the adjustment the yarn carrier.
Further information:
Adjusting yarn carriers [221]
When replacing the yarn carrier bow, ensure that the punch
mark is located on the inside when mounting shim (2).
