425
Repairing the knitting machine 7
Replacing parts
12. The gear racks must be aligned.
Monitoring of built-in p osition
Monitoring of built-in position
13. If this is not the case, repeat step 3 through 11.
14. Move pin of the lower gear rack guide at the
rear to the home position.
Replacement of the gear racks is com
plete.
Further information:
Removing and mounting step motor [420]
