5 Setup Data
Setup2 Editor
NPR (tab)
NPR (tab) Correction of the stitch cam position for the right carriage (for tandem
operation only)
Further information:
Table Tools [316]
File tools [317]
Helpers for Input [311]
Overview of the Setup2 Editor
of the CMS [
309]
Setup Data [303]
Comparing Setup1 to Setup2 [305]
Explanation
Value range
NPR
Correction of the stitch cam position for
the right carriage
Front
Correction value depending on system
in front or rear and on carriage
direction to the left or to the right
Minimum value: -2
Maximum value: 2
Step width: 0.05
Rear
<<
>>
NPxR
Correction value for the stitch cam
position x (1-100) of the right carriage
Value [mm]
Specification in NP values.
Minimum value: -2
Maximum value: 2
Step width: 0.05
Value [mm]
Specification in millimeters
Minimum value: -5.0
Maximum value: 5.0
Step width: 0.01
Comment
Comment
ASCII Characters
