150
4 Adjusting knitting machine
Basic settings
Set the maximum slack take-
up path of the yarn tensioner
If desired the maximum slack take-up path of the yarn tensioner can be set
from 80 to 35 degrees. This will be set with the lock segment (3). It has four
lock positions (A – D).
Position
max. angle
Explanation
A
80
Home position of the lock segment.
Active thread clamp in action
Largest yarn tensioning path
B
65
Active thread clamp in action
C
50
Active thread clamp in action
D
35
Active thread clamp out of action
Smallest yarn tensioning path
