152
4 Adjusting knitting machine
Basic settings
5. Check the yarn delivery.
6. Set all swivel bows consecutively with the scale (3) as described in steps
1 to 5.
For very coarse yarn (valid
for all types)
T
he distance between stop motion rail and friction roller is too small so that the
yarn comes into contact with the stop motion rail and releases a stop impulse,
then the machine stops.
Modifying the distance:
1. Remove the screw (5) and the stop motion rail (4).
Set the distance between stop motion rail and friction roller
Set the distance between stop motion rail and friction roller
2. Turn the stop motion rail by 180 degrees and assembly it again.
A bigger distance (6) is between the
stop motion rail and the friction roller.
Further information:
Symbols in this document [16]
Threading up threads into friction feed w
heel * [
86]
