Description of knitting machine 2
Components of the knitting machine
Overview machine elements 2
Overview machine elements 2
Designation
Explanation
9
Engaging rod
It activates and stops the carriage run.
10
Fabric take-down
(main take-down,
auxiliary take-down,
comb take-down, belt
take-down)
Main take-down:
Pulls the stitches away from the needle
downwards to the fabric c
ontainer.
Auxiliary take-down:
Grasps the fabric directly under the needle bed.
Comb take-down:
With the comb take-dow
n fabric piece
s are
automatically started and press off after
completion.
Belt take-down:
Grasps the fabric directly under the needle bed.
11
Fabric collection
chamber
The fabric take-down guides the finished fabric
into the fabric collection chamber. There the
fabric is protected from soiling.
12
Touch screen
The touch screen enables communication with
the machine control
13
USB port
Connection for a removable drive, containing
knitting programs, operating systems and
machine data.
Recommendations: Use USB Memory Stick.
Also
possible: F
loppy disk drive, CD drive, DVD
drive, external hard disk.
