210
4 Adjusting knitting machine
Advanced adjustments
The needle bed moves to the left and right. The racking will be
synchronized.
6. Tap the "Reference run V>REF" key. A message appears, answer this
with "Yes".
The needle bed moves to the left and right. The racking is carrying out
a r
eference run.
7. Program an empty row with half racking
and fix the knitting specification
[378].
8. Push up several opposing needles at various positions of the needle bed
(left, center, right) on both needle beds until the needle hooks touch each
other.
9. Check whether the needle hooks of the front and rear needle bed
are
exactly in a line.
10.
If this is not the case: Push back need
les somewhat so that they do not
touch each other anymore. In the "VGK" line, enter the value using the
linear regulator.
11. Confirm input.
The needle bed moves lightly to the left or ri
ght.
12. Check whether the needle hooks of the
front and rear needle bed are
exactly in a line.
13. If this is not the case, repeat steps 1
0 to 12 until the needle hooks of the
front and rear needle beds are exactly positioned in one line.
14. The VGK value is automatically saved in the data specific to the
machine
(dongle data).
15. Adjust VPK value [206].
(To be able to determine the VGK value you had to set the VPK value to
"0"
(in step 4). After having determined the VGK value you must set the
VPK value again.)
The
setting process is complete.
-1…-150
Correction to the left (1 step = 0.01 mm)
+1…+150
Correction to the right (1 step = 0.01 mm)
If you want, you can save the VGK-value additionally:
➜ on a USB memory stick [483]
➜ on a network drive (button "Copy Dongl
e") [201]
