386
7 Repairing the knitting machine
Replacing parts
10. Reassemble the needle and coupling part.
11. The end of the coupling part bumps into the wire (11), and must therefore
be pushed harder.
Tip: This is easier, if the needle is pres
sed into the needle bed.
12. Reassemble the holding-down jack bed in the r
everse order.
13. Retighten the screws (7) on
the jack bed.
Control: The holding-down jacks should be easily moved to t
he "Position
closed".
If this is not the case, the jack bed is
no in the correct position. Loosen the
screws again and shift the jack bed somewhat to the side. Retighten the
screws and check it again.
