448
7 Repairing the knitting machine
Check fuses
4. Inspect battery fuse (9).
Disconnect the plug 7 for this.
Remove the screw (8).
Pull out the battery plug-in unit.
Inspect battery fuse (9).
5. Check the ballast fuse (5) on the input and output card. For t
his purpose,
remove the screws at the top and bottom and pull out the card.
Ballast fuse f or servo drive and racking on the input and output card.
Ballast fuse for servo drive and racking on the input and output card.
DANGER
Burning risk!
Injuries by hot parts.
➜ Watch out not to touch the resistors (6) when pulling out the
board.
The resistors can get very hot.
