Commands Listed in Alphabetical Order
Examples
CURSOR:XY:RDE
LTA?
might return :CURSOR:XY: RDELTA 6.9600, indicating
that the d ifference between the c ursors radius is 6.9600 V.
CURSor:XY:READOUT
This command sets or queries the XY cursor readout (available when
DISplay:FORMat is set to XY).
Group
Cursor
Syntax
CURSor:XY:READOUT {RECTangular|POLA RCoord|PRODuct|R ATio}
CURSor:XY:READOUT?
Related Commands
DISplay:FORMat
Arguments
RECTangular displays the following values: X1, X2, ΔX, Y1, Y2, ΔY, t 1 , t 2, Δt.
POLARCoord displays the following values: r1, r2, Δr, q1, q2, Δq, t1, t2, Δt.
PRODuct displays the following values: X1 x Y1, X2 xY2, ΔXxΔY, t 1, t 2, ΔDt.
RATio displays the following values: Y1 ¸ X1, Y2 ¸ X2, ΔY¸xΔX, t1, t2, Δt.
Examples
CURSOR:XY:READOUT RECTangular sets the XY cursor readout to rectangular.
CURSOR:XY:READOUT? might return :CURSOR:XY:READOUT RECTANGULAR,
indicating that the XY cursor readout is set to rectangular mode.
CURSor:XY:RECTX<x>
This command sets or queries the X cursor position in rectangular coordinates.
Thecursorisspecified by x, which can be 1 or 2.
NOTE. This query is only valid when the CURSor:XY:READOUT is set to
RECTangular. If the readout is set other than rectangular coordinates, the IEEE
representation of NAN (Not a Number) is returned: 99.1000E+36.
Group
Cursor
Syntax
CURSor:XY:RECTX<x> {<NR3>}
CURSor:XY:RECTX<x>?
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-147
