Commands Listed in Alphabetical Order
Related Commands
MEASUrement:I
MMed:REFLevel:METHod
Arguments
<NR3> is the low reference level, in volts. The default is 0.0 V.
Examples
MEASUREMENT:IMMED:REFLEVEL :ABSOLUTE:LOW 0.0 sets the low reference
level to 0.0 V.
MEASUREMENT:IMMED:REFLEVEL :ABSOLUTE:LOW? might return
:MEASUREMENT:MEAS1:REFLEVE L:ABSOLUTE:LOW 0.0000E+00, indicating
that the absolute low reference level is set to 0.0 V.
MEASUrement:IMMed:REFLevel:ABSolute:MID<x>
This command sets or queries the mid reference level, and is the 50% reference
level when MEASUrement:IMMed:REFLevel:METHod is set to Absolute. Note
that this command affects the results of period, frequency, delay, and all cyclic
measurements. Note that this command affects the results of delay measure ments.
NOTE. This command affects the results of period, frequency, delay, and all
cyclic measurements.
Group
Measurement
Syntax
MEASUrement:IMMed:REFLevel :ABSolute:MID<x> <NR3>
MEASUrement:IMMed:REFLevel :ABSolute:MID<x>?
Related Commands
MEASUrement:IMMed:REFLevel:METHod
Arguments
<NR3> is the mid1 (the “from” waveform when taking a delay measurement) or
mid2 (the “to” waveform when taking a delay measurement) reference level,
in volts. The default is 0.0 V.
Examples
MEASUREMENT:IMMED:REFLEVEL :ABSOLUTE:MID2 0.5 sets the mid reference
level for the delay waveform to 0.5 V.
MEASUREMENT:IMMED:REFLEVEL :ABSOLUTE:MID2? might return
:MEASUREMENT:IMMED:REFLEVE L:ABSOLUTE:MID2 0.5000E+00, indicating
that the absolute mid2 reference level is set to 0.5 V.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-373
