Command Groups
Command
Description
TRIGger:A:SPI:DATa:MOSI:SOUrce Sets or queries the MOSI data source for the
SPI trigger
TRIGger:A:SPI:DATa:MOSI:VALue Sets or queries the binary data string u sed
for the SPI tr
igger if the trigger condition is
settoMOSIorMISOMOSI
TRIGger:A:SPI:DATa:STARt Sets or queries the nth data byte on the data
source after the signal on the enable slave
source swit
ches to the polarity specified by
the Slave Select Polarity
TRIGger:A:SPI:FO RM a t Sets or queries the SPI trigger data format
TRIGger:A:SPI:SCLK:ACTIVE Sets or queries the SPI SCLK polarity
TRIGger:A:SPI:SCLK:LEVel Sets or queries the threshold for the SPI
trigger SCLK
TRIGger:A:SPI:SCLK:SOU rce Sets or queries the S PI SCLK source
TRIGger:A:SPI:SS:ACTIVE Sets or queries the SPI trigger Slave Select
(SS) po
larity
TRIGg
er:A:SPI:SS:LEVel
Sets o
r queries the threshold for the SPI
trigger Slave Select (SS) signal
TRIGger:A:SPI:SS:SOUrce Sets or queries the SPI trigger Slave Select
(SS) source
Mask Command Group
Use
the commands in the Mask Command Group to compare incoming waveforms
against standard or u ser-defined telecommunications masks. Standard masks are
only available when option MTM is installed. Without option MTM, you need
to define your masks. When the instrument detects waveforms that fall inside or
outside of the mask limits, it can perform tasks such as generating hard copy,
saving the waveform, emitting a beep or an SRQ, stopping and waiting for your
i
nput, sending an E-mail message with specified data, logging the time/date of the
acquired waveform, or some combination of these actions.
A mask is a set of polygonal regions on the screen. Every vertical line of the
screen intersects the polygon in zero, one, or two places, but never in more than
two places. (A vertical line that intersec ts a vertical mask border is counted.) You
have to break up more complicated polygons into two separate segments. Unlike
limit testing, the inside of a mask is the region where waveform data would
not normally fall. A telecommunications standard requires up to eight of these
segments. Pulse standards always have two segments. Standards with eye patterns
usually have three masks, but some have four.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-31
