Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
TRIGger:A:RS232:FORMat Sets or queries the display format for the
RS232 data value
TRIGger:A:RS232:PARity Sets or queries the state of the RS232 parity
bit
TRIGger:A:
SERIAL:BITRate
Sets or quer
ies the clock/data bit rate
TRIGger:A:
SERIAL:CLOCk:LEVel
Sets or quer
ies the serial trigger clock level
TRIGger:A
:SERIAL:CLOCk:POLarity
Sets or que
ries the serial clock polarity
TRIGger:
A:SERIAL:CLOCk:SOUrce
Sets or qu
eries the serial data source
channel
TRIGger:A:SERIAL:CODe Sets or queries the signal code
TRIGger:A:SERIAL:DATa:FORMat Sets o r queries how the Pattern string is
formatted
TRIGger:A:SERIAL:DATa:PATtern Sets or queries the data pattern to allow up
to 64 bi
t serial patterns
TRIGg
er:A:SERIAL:DATa :PATtern:NRZ
Sets o
r queries the data pattern to allow up
to 64 bit serial patterns
TRIGger:A:SERIAL:DATa:PATtern:S8B10B Sets or queries the data pattern to allow up
to 64 bit serial patterns
TRIGger:A:SERIAL:LOCKLen Sets or queries the length in bits of the
repe
ating bit pattern for pattern lock trigger
TRI
Gger:A:SERIAL:LOCKOffset
Set
s or queries the current bit o ffset into the
pattern lock trigger bit pattern
TRIGger:A:SERIAL:SOUrce Sets or queries the serial data source
channel
TRIGger:A:SERIAL:STANdard Sets or queries the standard that identifies
t
he code and bit rate
T
RIGger:A:SERIAL:TRIGgeron
S
ets or queries the trigger on a designated
arbitrary bit pattern or lock on a repeating
pattern of known length
TRIGger:A:SPI:CON Dition Sets or queries the trigger condition for SPI
triggering
TRIGger:A:SPI:DATa:MISO:ACTIVE Sets or queries the SPI MISO polarity
TRIGger:A:SPI:DATa:MISO:LEVel Sets or queries the threshold for the SPI
MISO data source
TRIGger:A:SPI:DATa:MISO:SOUrce Sets or queries the MISO data source for the
SPI trigger
TRIGger:A:SPI:DATa:MISO:VALue Sets or queries the binary data string used
for the SPI trigger if the trigger condition is
set to MISO or MISOM OSI
TRIGger:A:SPI:DATa:MOSI:ACTIVE Sets or queries the SPI MOSI polarity
TRIGger:A:SPI:DATa:MOSI:LEVel Sets or queries the threshold for the SPI
MOSI data source
2-30 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
