Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command Description
TRIGger:MULTiscope:DELay? Returns the delay time for trigger out of the
TekLink trigger out line
TRIGger:MULTiscope:LOGic Sets or queries the role of the instrument in
the MultiSco
pe trigger network
TRIGger:MU
LTiscope:OPTion
Sets or retu
rns the trigger type for the
TekLink trigger
TRIGger:MULTiscope:ROLe Sets or returns the role of the instrument
in the MultiS cope trigger network, either
PRODUCER o
rCONSUMER
Trigger Command Group
Use the commands in the Trigger Command Group to control all aspects of
triggering for the instrument.
There are two triggers: A and B. Where appropriate, the command set has parallel
constructions for each trigger.
You c an set the A or B triggers to edge mode. Edge triggering lets you display
a waveform at or near the point where the signal passes through a voltage level
of your choosing.
You can also set A or B triggers to pulse or logic modes. With pulse triggering,
the instrument triggers whenever it detects a pulse of a certain width or height.
Logic triggering lets you logically combine the signals on one or m ore channels.
The instrument then triggers when it detects a certain combination of signal levels.
Video triggering enables you to trigger on the most common Standard Definition,
High Definition, and custom video standards. You can trigger on all fields, all
lines, or individual video lines. Video trigger commands are only available on
DPO7000 instruments.
If you have Option MTM (Mask Testing) installed, you also have access to a
communication mode. When this mode is selected, several communication trigger
commands are available that work in conjunction with the mask c o
mmands. Refer
to Mask Command Group.
Command
Description
TRIGger
Forces a trigger event to occur or returns
current trigger parameters for the instrument
TRIGger:A Sets A trigger level to 50% or returns current
A trigger parameters
TRIGger:{A|B}:EDGE:COUPling Sets or returns the type of coupling for the
edge trigger
TRIGger:{A|B}:EDGE:SLOpe Sets or returns the slope for the edge trigger
TRIGger:{A|B}:EDGE:SLOpe:AUX Sets or returns the slope for the edge trigger
for the AUX In input
2-56 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
