Command Groups
Command
Description
LIMit:SRQ Sets or queries whether a Service Request
Interrupt (SRQ) is generated when the
waveform data
falls outside of the test limits
LIMit:STATE Sets limit te
sting on or off or queries whether
limittestingisineffect
LIMit:STATus? Queries the state of l imit testing
LIMit:STOPOnviolation Sets o r queries whether acquisitions are
stopped when the waveform data exceeds
the test li
mits
LIMit:TE
MPlate:STORe
Saves the
specified source waveform to the
specified reference or file name
LIMit:TEMPlate:TOLerance:HORizontal Sets or queries the amount, in units of
horizontal divisions, by which the source
wavefor
m is varied horizontally when
creating the destination waveform
LIMit:TEMPlate:TOLerance:VERTical Sets or queries the amount, in units of
vertical divisions, by which the source
wavefo
rm is v a ried vertically when creating
the destination w aveform
LIMit:TEMPlate:DESTination Sets or queries destination reference
waveform that the l imit template
LIMit:TEMPlate:SOUrce Sets or queries the channel, math
wave
form, or reference w aveform that the
LIMit:TEMPlate:STORe command will use
Low
Speed Serial Trigger Command Group
DPO7000 Series only: Use the commands in the Low Speed Serial Trigger
Command Group to control serial triggering for the instrument. CAN trigger
co
mmands are only available with the CAN option.
Command
Description
TRIGger:A:CAN:C ON Dition Sets or returns the CAN condition
TRIGger:A:CAN:D ATa:DIRection Sets or queries the CAN trigger condition to
be valid on a READ, WRITE, or either
TRIGger:A:CAN:F OR Mat Sets or queries the CAN data format
TRIGger:A:CAN:DATa:LEVel Sets or queries the CAN Trigger threshold
for the CAN data source
TRIGger:A:CAN:DATa:SOUrce Sets or queries the CAN data source
TRIGger:A:CAN:DATa:VALue Sets or queries the binary data string used
for CAN Trigger if the trigger condition is ID
or IDANDDATA
TRIGger:A:CAN:F RAM E ty pe Sets or queries the CAN trigger frame type
2-28 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
