Commands Listed in Alphabetical Order

NOTE. This comm

and affects the associated reference level parameter

for all MEASurements:IMMed and the eight periodic measurements.

To change the parameter for individual measurements, use the

MEASUrement:MEAS<x>:REFLevel commands.

Group

Measurement

Syntax

MEASUrement:REFLevel:PERCe nt:LOW <NR3>

MEASUrement:REFLevel:PERCe nt:LOW?

Related Commands

EASUrement:REFLevel:METHod, MEASUrement:IMMed:TYPe,

MEASUrement:MEAS<x>:TYPe

Arguments

<NR3> is the low reference level, ranging from 0 to 100%. The default low

reference level is 10%.

Examples

MEASUREMENT:REFLEVEL:PERCE NT:LOW 15 sets the high reference level to

15% of HIGH.

MEASUREMENT:REFLEVEL:PERCE NT:LOW? might return

:MEASUREMENT:REFLEVEL:PERC ENT:LOW 10, indicating that the

percentage high reference level is set to 10% of HIGH.

MEASUrement:REFLevel:PERCent:MID<x>

This command sets or queries the percent (where 100% is equal

to HIGH) that is used to calculate the mid reference level when

MEASUrement:REFLevel:METHod is set to Percent. Mid1 speciﬁes the percent

for the ﬁrst waveform and Mid2 speciﬁes the percent for the second waveform

speciﬁed for delay measurements. This command affects the results of period,

frequency, delay, and all cyclic measurements and is equivalent to selecting

Reference Levels from the Measure menu, and then entering the Percentage Mid

Ref value.

NOTE. This command affects the associated reference level parameter

for all MEASurements:IMMed and the eight periodic measurements.

To change the parameter for individual measurements, use the

MEASUrement:MEAS<x>:REFLevel commands.

Group

Measurement

DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-407
