Commands Listed in Alphabetical Order
TRIGger:AUXle
vel?
might return :TRIGGER:AUXLEVEL TTL, indicating that
the auxiliary level for the edge trigger is set to TTL.
TRIGger:B (No Query Form)
This command sets the B trigger level to 50% of minimum and maximum. The
query form of this command returns the B trigger parameters. This command is
similar to selecting B Event (Delayed) Trigger Setup from the Trig menu and
then viewi
ng the current setups.
Group
Trigger
Syntax
TRIGger:B SETLevel
Related Commands
TRIGger:A TRIGger:B:STATE
Arguments
SETLevel sets the B trigger level to 50% of M IN and MAX.
Examples
TRIGGER:B SETLEVEL sets the B trigger l evel to 50% of MIN and MAX.
TRIGGER:B? might return the following B trigger parameters:
:TRIGGER:B:STATE 0;TYPE EDGE; LEVEL -220.0000E-3;BY
TIME;EDGE:SOURCE CH1;SLOPE RISE;COUPLING DC; :TRIGGER:B: TIME
16.0000E-9;EVENTS:COUNT 2
.
TRIGger:B:BY
This command selects or returns whether the B trigger occurs after a spec ified
number of events or a specified period of time after the A trigg
er. This is
equivalent to selecting B Event (Delayed) Trigger Setup from the Trig menu,
selecting the A →B Seq tab, and then choosing Trig After Time or Trig on nth
event.
NOTE. The traditional Runs After functionality is now served by the Horizontal
Delay function. For details, see the HORizontal[:MAIn]:DELay:MODe and
HORizontal[:MAIn]:DELay:TIMe commands.
Group
Trigger
2-608 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
