Commands Listed in Alphabetical Order
MEASUREMENT:I
MMED:REFLEVEL:PERCENT:LOW?
might return
:MEASUREMENT:IMMED:REFLEV EL:PERCENT:LOW 10, indicating that the
percentage low reference level is set to 10% of HIGH.
MEASUrement:IMMed:REFLevel:PERCent:MID<x>
This command sets or queries the percentage (where 100% is equal to HIGH) used
to calculate the mid reference level when MEASUrement:IMMed:REFLevel:
METHod is set to Percent. Mid1 is for the first waveform specified, and Mid2 is
for the second waveform specified. Note that this command affects the results
of delay measurements.
NOTE. This command affects the results of period, frequency, delay, and all
cyclic measurements.
Group
Measurement
Syntax
MEASUrement:IMMed:REFLeve l:PERCent:MID<x> <NR1>
MEASUrement:IMMed:REFLeve l:PERCent:MID<x>?
Related Commands
MEASUrement:IMMed:REFLevel:METHod
Arguments
<NR1> is the mid reference level, ranging from 0 to 100%. The default mid
reference level is 50%.
Examples
MEASUREMENT:IMMED:REFLEVE L:PERCENT:MID2 40 sets the mid2 reference
level to 40% of HIGH.
MEASUREMENT:IMMED:REFLEVE L:PERCENT:MID2? might return
:MEASUREMENT:IMMED:REFLEV EL:PERCENT:MID2 45, indicating that the
percentage mid2 reference level is set to 45% of HIGH.
MEASUrement:IMMed:SOUrce<x>
This command sets or queries the source for phase o r delay immediate
measurements. This command is equivalent to selecting Measurement Setup
from the Measure menu, choosing the Time tab, clicking the Delay button to
display the delay settings and then clicking the desired Source1 (From) setting or
Source2 (To) setting.
Tip: Source2 measurements only a pply to phase and delay measurement types,
which require both a target (Source1) and reference (Source2) source.
2-376 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
