Commands Listed in Alphabetical Order
TRIGGER:A:PUL
SE:TRANSITION:POLARITY?
might return
:TRIGGER:A:PULSE:TRANSITI ON:POLARITY EITHER, indicating that the
transition can be either positive or negative for trigger A.
TRIGger:{A|
B}:PULse:TRANsition:QUAlify
This command sets or queries the Transition Time Trigger qualification.
This is equivalent to selecting Transition Setup from the Trig menu and selecting
Occurs or Logic in the Trigger if Violation drop-down list box.
NOTE. If you use the LOGIc argument, you must specify the channel logic
conditio
ns.
Group
Trigger
Syntax
TRIGger:{A|B}:PULse:TRANs ition:QUAlify {OCCurs|LOGIc}
TRIGger:{A|B}:PULse:TRANs ition:QUAlify?
Arguments
OCCurs specifies a trigger if any violations occur.
LOGIc specifies a trigger if the individual channel qualifications meet the logic
patterns and thresholds set by the TRIGger:{A|B}:LOGIC:INPUT:CH<x> and
TRIGGER:{A|B}:LOGIC:THRESHOLD:CH<x> commands.
Examples
TRIGGER:A:PULSE:TRANSITIO N:QUALIFY OCCURS sets the trigger qualifier
to OCCurs, which initiates an A trigger if the instrument detects any transition
violations.
TRIGGER:A:PULSE:TRANSITIO N:QUALIFY? might return
:TRIGGER:A:PULSE:TRANSITI ON:QUALIFY OCCURS, indicating
that an A trigger will occur if the instrument detects any transition violations.
TRIGger:{A|B}:PULse:TRANsition:THReshold? (Query Only)
This query-only command returns the upper and lower threshold limits for the
transition time trigger. This command is equivalent to selecting Transition Setup
from the Trig menu and viewing the Upper Level and Lower Level voltage
settings.
Group
Trigger
2-538 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
