Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
Examples
HORIZONTAL:FA
STFRAME:TIMESTAMP:BETWEEN:CH 1? 5,2
might
return
:HORIZONTAL:FASTFRAME:TIMES TAMP:BETWEEN:CH1
5,2,"00:00:00.010 000 540 624"
This is the delta of Channel 1’s Time
Stamp frame 5 - Time Stamp frame 2 (TS[5]-TS[2]).
HORizontal:FASTframe:TIMEStamp:DELTa:<wfm>? (Query O nly)
This query-only command returns the relative time between the triggers o f the
FastFrame Selected and the FastFrame Reference, within the specified waveform.
Valid waveforms include CH<x>, MATH<x>, and REF<x>. The x variable c
an
be expressed as an integer ranging from 1 through 4.
The format of the output is as follows:
HH:MM:SS.xxx xxx xxx xxx
HH:MM
:SS is hours, m inutes, and seconds
.xxx xxx xxx xxx is fractions of a second to picoseconds
Group
Horizontal
Syntax
HORizontal:FASTframe:TIME Stamp:DELTa:<wfm>?
Examples
HORIZONTAL:FASTRAME:TIMES TAMP:DELTA:CH1? might return
:HORIZONTAL:FASTFRAME:TIM ESTAMP:DELTA:CH1 "00:00:00.006 000
306 556 "
This is the delta time stamp of FastFrame Selected Frame on Channel 1
- FastFrame Reference Frame (TS[C1 Selected]-TS[Reference]).
HORizontal:FASTframe:TIMESta mp:FRAMe:<wfm>? (Query Only)
This query-only command returns the absolute trigger date and time for the
specified frame and waveform. Valid waveforms include CH<x>, MATH<x> and
REF<x>. The x variable can be expressed as an integer ranging from 1 through 4.
The format of the output is as follows:
DD MON YYYY HH:MM:SS.xxx xxx xxx xxx
DD MON YYYY is day, month, and year
HH:MM:SS is hours, minutes, and seconds
.xxx xxx xxx xxx is fractions of a second to picoseconds
Group
Horizontal
2-250 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
