Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
to selecting Re
ference Levels from the Measure menu, and then entering the
Absolute Low Ref value.
NOTE. this command affects the associated reference level parameter
for all MEASurements:IMMed and the eight periodic measurements.
To change the parameter for individual measurements, use the
MEASUrement:MEAS<x>:REFLevel commands.
Group
Measurement
Syntax
MEASUrement:REFLevel:ABSo lute:LOW <NR3>
MEASUrement:REFLevel:ABSo lute:LOW?
Related Commands
MEASUrement:REFLevel:METHod, MEASUrement:IMMed:TYPe,
MEASUrement:MEAS<x>:TYPe
Arguments
<NR3> is the low reference level, in volts. The default is 0.0 V.
Examples
MEASUREMENT:REFLEVEL:ABSO LUTE:LOW 0.0 sets the low reference level
to 0.0 V.
MEASUREMENT:REFLEVEL:ABSO LUTE:LOW? might return
:MEASUREMENT:REFL
EVEL:ABSOLUTE:LOW 0.0000E+00
, indicating that the
absolute low reference level is set to 0.0 V.
MEASUrement:REFLevel:ABSolute:MID<x>
This command sets or queries the mid reference level for the “from” waveform
(mid1) and the “to” waveform (mid2) when taking a delay measurement, and
is the 5 0% reference level when MEASUrement:REFLevel:METHod is set to
Absolute. This c
ommand affects the results of period, frequency, delay, and all
cyclic measurements and is equivalent to selecting Reference Levels from the
Measure menu, and then entering the Absolute Mid2 Ref value.
NOTE. This command affects the associated reference level parameter
for all MEASurements:IMMed and the eight periodic measurements.
To change the parameter for individual measurements, use the
MEASUrement:
MEAS<x>:REFLevel commands.
Group
Measurement
2-404 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
