Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
Table 2 -19: Communication Trigger Standards (cont.)
Argument Code Bit Rate Mask Type Models
OC48 FEC
NRZ
2.666 Gb/s Sonet
PCIEXPRESS
NRZ
2.5 Gb/s PCI-Express
RATE32Mbit NRZ
32.064 Mb/s
ITU
RATE97Mbit NRZ
97.728 Mb/s
ITU
RIO_500M
NRZ
500 Mb/s RapidIO/LP-LVDS ≥1.0 GHz
RIO_750_M
NRZ
1 Gb/s RapidIO/LP-LVDS
RIO_1G
NRZ
1 Gb/s RapidIO/LP-LVDS
RIO_1_5_G
NRZ
2 Gb/s RapidIO/LP-LVDS
RIO_SERIAL_1G
NRZ
1.25 Gb/s RapidIO/LP-LVDS
RIO_SERIAL_2G
NRZ
2.5 Gb/s RapidIO/LP-LVDS
RIO_SERIAL_3G
NRZ
3.125 Gb/s RapidIO/LP-LVDS
SAS1_5
NRZ
SAS
SAS3_?
NRZ
SAS
SFI5_2
NRZ
2.488 Gb/s OIF
SFI5_3
NRZ
3.125 Gb/s OIF
STM0_CMI
NRZ
51.84 Mb/s
ITU
STM0_HDBX
NRZ
51.84 Mb/s
ITU
STM1E
NRZ
155.52 Mb/s
ITU
STS1
NRZ
51.840 Mb/s ANSI T1.102
STS3
NRZ
155.52 Mb/s ANSI T1.102
TFI5_2 NRZ
2.488 Gb/s OIF
TFI5_3 NRZ
3.1104 Gb/s OIF
VIDEO270
NRZ
270 Mb/s
Video ≥500 MHz
VIDEO292M
NRZ
1.485 Gb/s
Video
≥2.5 GHz
VIDEO360
NRZ
360 Mb/s
Video ≥500 MHz
VSROC192
NRZ
1.24116 Gb/s OIF
Examples
TRIGGER:A:COMMUNICATION:ST ANDARD E4 sets the standard to E4.
TRIGGER:A:COMMUNICATION:ST ANDARD? might return
:TRIGGER:A:COMMUNICATION:S OURCE:STANDARD DS1.
TRIGger:A:HOLDoff? (Query Only)
This query-only command returns the A trigger holdoff parameters. These
parameters specify the time period during which the trigger circuitry is not looking
to generate a trigger event. This command is equivalent to selecting Holdoff from
the Trig menu and then viewing the current settings.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-565
