Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
Table 2-19: Communication Trigger Standards (cont.)
Argument Code Bit Rate Mask Type Models
D1 NRZ
270 Mb/s
Video All
D2 NRZ
143.18 Mb/s
Video All
DS0 Contra
AMI
16.0 kb/s ITU-T G.730
All
DS0 Double
AMI
32.0 kb/s ITU-T G.730
All
DS0 Single
AMI
64.0 kb/s ITU-T G.730
All
DS0 Timing
AMI
32.0 kb/s ITU-T G.730
All
DS1 AMI B8ZS 1.544 Mb/s ANSI T1.102
All
DS1A
AMI HDB3
2.048 Mb/s ANSI T1.102
All
DS1C AMI B8ZS 3.152 Mb/s A NSI T1.102
All
DS2 AMI B6ZS 6.312 Mb/s ANSI T1.102
All
DS2RATE Coax AMI B8ZS 6.312 Mb/s ITU-T G .703
All
DS2RATE
Symmetrical
AMI B6ZS 6.312 Mb/s ITU-T G.703
All
DS3 AMI B3ZS 44.736 Mb/s ANSI T1.102
All
DS4NA CMI 139.3 Mb/s ANSI T1.102
All
E1 AMI HDB3
2.048 Mb/s ITU-T G.703
All
E2 AMI HDB3
8.448 MB/s ITU-T G .703
All
E3 AMI HDB3
34.368 Mb/s ITU-T G .703
All
E4
CMI 139.26 Mb/s ITU-T G.703
All
ENET100 MLT3
100 Mb/s
Ethernet All
ENET1250 NRZ
1.25 Gb/s
Ethernet
≥2.5 GHz
ENETXAU NRZ
3.125 Gb/s
Ethernet
≥
FC133
NRZ
132.8 Mb/s Fibre Channel
All
FC266
NRZ
265.6 Mb/s Fibre Channel
All
FC531
NRZ
531.2 Mb/s Fibre Channel ≥1.0 GHz
FC1063
NRZ
1.0625 Gb/s Fibre Channel
FC2125
NRZ
2.125 Gb/s Fibre Channel
FC4250
NRZ
4.256 Gb/s Fibre Channel
FST
NRZ
12.0 Mb/s USB 1.1/2.0
All
FW1394 BS400B
NRZ
491.5 Mb/s
IEEE1394b
≥1.0 GHz
FW1394 BS1600B
NRZ
1.966 Gb/s
IEEE1394b
HST
NRZ
480 Mb/s USB 1.1/2.0 ≥1.0 GHz
INF_5G
NRZ
2.5 Gb/s Infiniband
OC1
NRZ
51.84 Mb/s SONET/SDH
All
OC3
NRZ
155.52 Mb/s S ONET/SDH
All
OC12
NRZ
622.08 Mb/s S ONET/SDH ≥1.0 GHz
OC48
NRZ
2.4883 Gb/s S onet
2-564 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
