Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
TRIGger:{A|B
}:PULse:WINdow:QUAlify
This command sets or queries the Window Trigger qualification. This is
equivalent to selecting Window Setup from the Trig menu and selecting Occurs or
Logic in the T
rigger if Window drop-down list box.
NOTE. If you use the LOGIc argument, you must specify the channel logic
conditions.
Group
Trigger
Syntax
TRIGger:{A|B}:PULse:WINdow :QUAlify {OCCurs|LOGIc}
TRIGger:{A|B}:PULse:WINdow :QUAlify?
Arguments
OCCURS specifies a trigger if any detectable event occurs.
LOGIC specifies a trigger if the individual channel qualifications meet the logic
patterns and thresholds set by the
TRIGger:{A|B}:LOGIC:INPUT: CH<x> and
TRIGGER:{A|B}:LOGIC:THRESH OLD:CH<x> commands.
Examples
TRIGGER:A:PULSE:WINDOW:QUA LIFY OCCURS sets the trigger q
ualifier to
OCCURS, which causes an A trigger to occur if the instrument detects any of the
window trigger qualifications.
TRIGGER:A:PULSE:WINDOW:QUA LIFY? might return
:TRIGGER:A:PULSE:WINDOW:QU ALIFY OCCURS, indicating that an A trigger
will occur if the instrument detects any of the window qualifications.
TRIGger:{A|B}:PULse:WINdow:THReshold? (Query Only)
This query-only command returns the upper and lower thresholds for the window
trigger. This command query is equivalent to selecting Window Setup from the
Trig menu and viewing the window trigger Upper Level and Lower Level settings.
Group
Trigger
Syntax
TRIGger:{A|B}:PULse:WINdow :THReshold?
Examples
TRIGGER:A:PULSE:WINDOW:THR ESHOLD? might return
:TRIGGER:A:PULSE:WINDOW:TH RESHOLD:HIGH 1.2000;LOW
800.0000E-3
, indicating that the upper threshold is 1.2 V and that the lower
threshold is 800 mV.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-547
