Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
MEASUrement:STATIstics:MO De Turns measurement statistics on or off
and sets or returns which pair of statistical
accumulation
s is displayed
MEASUrement
:STATIstics:WEIghting
Sets or retur
ns the ’time constant’ for
mean and standard deviation statistical
accumulations
Miscellaneous Command Group
Miscellan
eous commands do not fit into other categories.
Several commands and queries are common to all 488.2-1987 devices on the
GPIB bus.
The 488.2-1987 standard defines these commands. The common
commands begin with an asterisk (*) character.
Command
Description
AUXout?
Returns the auxiliary out setup
AUXout:EDGE Sets or returns the direction in which the
trigger output signal will transition when a
trigger occurs
AUXout:SOUrce Sets or returns the trigger source at the BNC
connection
AUTOSet Sets the vertical, horizontal, and trigger
controls of the instrument to automatically
acquire and display the selected waveform
BELl In previous models, this command sounded
the audio indicator. Provided for backward
compatibility
CMDBatch Turns command batching on or off
Or returns the state of command batching
DATE
Sets or returns the date that the instrument
can display
*DDT Sets or returns the commands that will be
executed by the group execute trigger
HEADer
Sets or returns the Response Header Enable
State
HDR
Sets or returns the Response Header Enable
State
ID? Returns identifying information about the
instrument and its firmware
*IDN? Returns the instrument identification code
LOCk Sets or returns the front panel lock state
*LRN? Returns a listing of instrument settings
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-43
