Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
Group
Limit Test
Syntax
LIMit:TEMPlate:DESTinatio n {REF1|REF2|REF3|REF4}
LIMit:TEMPlate:DESTinatio n?
Arguments
REF<x> specifies the reference waveform destination in which the template
waveform is to be stored.
Examples
LIMIT:TEMPLATE:DESTINATIO N REF2 specifies that the t emplate waveform
referred to with the LIMit:TEMPlate:STORe command is stored as the REF2
waveform.
LIMIT:TEMPLATE:DESTINATIO N? might return :LIMIT:TEMPLATE:
DESTINATION REF3
, indicating the REF3 waveform is used to store the template
waveform referred t
o with the LIMit:TEMPlate:STORe command.
LIMit:TEMPlate:SOUrce
This command sets or queries the channel, math waveform, or reference waveform
that the LIMit:TEMPlate:STORe command will use.
NOTE. The command works only if the LT Limit Test option is enabled.
Group
Limit Test
Syntax
LIMit:TEMPlate:SOUrce
{CH1|CH2|CH3|CH4|MATH1|MA TH2|MATH3|MATH4|REF1|REF2|REF3|REF4}
LIMit:TEMPlate:SOUrce?
Arguments
CH<x> specifies the channel used by the LIMit:TEMPlate:STORe command.
Math<x> specifies the math waveform used by the LIMit:TEMPlate:STORe
command.
REF<x> specifies the reference waveform used by the LIMit:TEMPlate:STORe
command.
Examples
LIMIT:TEMPLATE:SOURCE CH2 specifies that the template waveform for limit
tests is the waveform currently acquired using Channel 2.
LIMIT:TEMPLATE:SOURCE? might return :LIMIT:TEMPLATE:SOURCE MATH3,
indicating that the template waveform for limit tests is the waveform currently
stored as the Math 3 waveform.
2-276 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
