Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
TRIGger:A:CAN:ID ENTifier:MODe Sets or queries the CAN trigger identifier
mode
TRIGger:A:CAN:ID ENTifier:VALue Sets or queries the binary address string
used for the C
AN trigger if the trigger
condition is ID or IDANDDATA
TRIGger:A:CAN:PRO BE Sets or queries the probing method used to
probe the CAN signal
TRIGger:A:CAN:SPEed Sets or queries the bit rate of the CAN
system
TRIGger:
A:I2C:ADDRess:MODe
Sets or qu
eries the I2C address mode to 7
or 10-bit
TRIGger:A:I2C:ADDRess:RWINClude Sets or queries the I2C address mode to
include the read/write bit as an additional 8th
bitofth
e 7–bit address
TRIGger
:A:I2C:ADDRess:TYPe
Sets or q
ueries the I2C address type
TRIGge
r:A:I2C:ADDRess:VALue
Sets or
queries the binary address string
used for the I2C trigger if the trigger condition
is ADDR or ADDRANDDATA
TRIGger:A:I2C:CLOCk:LEVel Sets or queries the clock source for the I2C
Seria
l Trigger
TRIG
ger:A:I2C:CLOCk:SOUrce
Sets
or queries the clock source for the I2C
Serial Trigger
TRIGger:A:I2C:CON Dition Sets or queries the trigger condition for the
I2C trigger
TRIGger:A:I2C:DATa:DIRection Sets or queries the I2C trigger condition valid
on
a READ, WRITE, or either
TR
IGger:A:I2C:DATa:LEVel
Se
ts or queries the threshold level for the
I2C data source
TRIGger:A:I2C:DATa:SOUrce Sets or queries the data source for the I2C
serial trigger
TRIGger:A:I2C:DATa:STARt Sets or queries the data start byte
TRIGger:A:I2C:DATa:VALue Sets or queries the binary data string used
for I2C triggering if the trigger condition is
DATA or ADDRANDDATA
TRIGger:A:I2C:FOR Mat Sets or queries the display format for the I2C
data value
TRIGger:A:RS232:BAUd Sets or queries the baud rate for RS232
triggering
TRIGger:A:RS232:DATa:LEVel Sets or queries the threshold for the RS232
data source
TRIGger:A:RS232:DATa:SOUrce Sets or queries the RS232 data source
TRIGger:A:RS232:DATa:VALue Sets or queries the binary data string used
for RS232 triggering
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-29
