Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
CH<x>:PRObe:SET Sets or queries aspects of probe accessory
user interfaces, for example probe
attenuation f
actors
CH<x>:PRObe
:SIGnal
Sets or queri
es aspects of probe accessory
user interfaces
CH<x>:PRObe:TIPtype Sets or returns the type of probe tip being
used on the specified channel
CH<x>:PRObe:UNIts? Returns the units of the probe that is attached
to the spec
ified channel
CH<x>:PR
OBECal?
Returns the probe calibration status
CH<x>:PR
OBECOntrol
Sets or qu
eries the probe range
CH<x>:P
ROBEFunc:EXTAtten
Sets the
attenuation value for the specified
channel to the specified scale factor
Or returns the user-specified attenuation
CH<x>:PROBEFunc:EXTDBatten Sets the attenuation value for the specified
channe
l to the specified value, in decibels
Or returns the user-specified attenuation, in
decibels
CH<x>:PROBEFunc:EXTUnits Sets the unit of measurement for the external
atten
uator of the specified channel
Or returns the user-specified unit of
measurement for the external attenuator
CH<x>:SCAle Sets or returns the vertical scale of the
spe
cified channel
CH<
x>:TERmination
Set
s channel input termination
RE
F<x>:HORizontal:POSition
Se
ts or returns the horizontal position of the
specified reference waveform in percent of
the waveform that is displayed to the right of
th
e center vertical graticule
R
EF<x>:LABel?
Returns a branch query containing the
w
aveform label name and the coordinates at
which the label is displayed
R
EF<x>:LABel:NAMe
Sets or returns the label of the designated
waveform
REF<x>:LABel:XPOS Sets or returns the position of the reference
waveform label on the X axis
REF<x>:LABel:YPOS Sets or returns the position of the reference
waveform label on the Y axis
REF<x>:VERTical:POSition Sets or returns the vertical position of the
specified reference waveform
REF<x>:VERTical:SCAle Sets or returns the reference waveform
vertical scale in vertical units/div
SELect? Returns information on which waveforms are
on or off and which waveform is selected
2-66 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
