Command groups
Table 2-31: Measurement commands (cont.)
Command
Description
MEASUrement:REFLevels:PERCent:RISEMid Sets or queries the percentage used to calculate the mid reference l evel of the rising
edge.
MEASUrement:REFLevels:PERCent:TY PE Sets or queries the reference level percent type.
MEASUrement:REFLevels:TYPE This command sets or queries the shared reference level method used for sources
of measurement calculations.
MEASUrement:REF<x>:REFLevels:ABSolute:
FALLHigh
Sets or queries the value used as the high reference level of the falling edge.
MEASUrement:REF<x>:REFLevels:ABSolute:
FALLLow
Sets or queries the value used as the low reference level of the falling edge.
MEASUrement:REF<x>:REFLevels:ABSolute:
FALLMid
Sets or queries the value used as the mid r eference level of the falling edge.
MEASUrement:REF<x>:REFLevels:ABSolute:
HYSTeresis
Sets or queries the value of the hysteresis of the reference level.
MEASUrement:REF<x>:REFLevels:ABSolute:
RISEHigh
Sets or queries the value used as the high reference level of the r ising edge.
MEASUrement:REF<x>:REFLevels:ABSolute:
RISELow
Sets or queries the value used as the low reference level of the rising edge.
MEASUrement:REF<x>:REFLevels:ABSolute:
RISEMid
Sets or queries the value used as the mid reference level of the rising edge.
MEASUrement:REF<x>:REFLevels:ABSolute:
TYPE
Sets or queries the reference level type.
MEASUrement:REF<x>:REFLevels:BASETop Sets or queries the method used to calculate the TOP and BASE, used to calculate
reference levels.
MEASUrement:REF<x>:REFLevels:METHod Sets or queries the method used to calculate reference levels.
MEASUrement:REF<x>:REFLevels:PERCent:
FALLHigh
Sets or queries the percentage used to calculate the high reference level of the falling
edge.
MEASUrement:REF<x>:REFLevels:PERCent:
FALLLow
Sets or queries the percentage used to calculate the low reference level of the falling
edge.
MEASUrement:REF<x>:REFLevels:PERCent:
FALLMid
Sets or queries the percentage used to calculate the mid reference level of the falling
edge.
MEASUrement:REF<x>:REFLevels:PERCent:
HYSTeresis
Sets or queries the percentage used to calculate the hysteresis of the reference level.
MEASUrement:REF<x>:REFLevels:PERCent:
RISEHigh
Sets or queries the percentage used to calculate the high reference level of the rising
edge.
MEASUrement:REF<x>:REFLevels:PERCent:
RISELow
Sets or queries the percentage used to calculate the low reference level of the rising
edge.
MEASUrement:REF<x>:REFLevels:PERCent:
RISEMid
Sets or queries the percentage used to calculate the mid reference level of the rising
edge.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-51
