Tektronix MSO56 User Manual

Command groups
Table 2-31: Measurement commands (cont.)
Command
Description
MEASUrement:MEAS<x>:TYPe
This command sets or queries the measurement type.
MEASUrement:MEAS<x>:WINDOWLENgth This command sets or queries the window length for the measurement.
MEASUrement:MEASRange:MAX
This command sets or queries the global range maximum value.
MEASUrement:MEASRange:MIN
This command sets or queries the global range minimum value.
MEASUrement:MEASRange:STATE Sets or queries the global range state.
MEASUrement:MINUI This command sets or queries the minimum number of unit intervals required for
BUJ analysis.
MEASUrement:POPUlation:LIMIT:STATE
This command sets or queries the global population limit state.
MEASUrement:POPUlation:LIMIT:VALue
This command sets or queries the global population limit value.
MEASUrement:REFLevels:ABSolute:FA LLHigh Sets or queries the value used as the high reference level of the falling edge.
MEASUrement:REFLevels:ABSolute:FALLLow S ets or queries the value used as the low reference level of the falling edge.
MEASUrement:REFLevels:ABSolute:FALLMid Sets or queries the value used as the mid reference level of the falling edge.
MEASUrement:REFLevels:ABSolute:
HYSTeresis
Sets or queries the value of the hysteresis of the reference level.
MEASUrement:REFLevels:ABSolute:RISEHigh Sets or queries the value used as the high reference level of the rising edge.
MEASUrement:REFLevels:ABSolute:RISELow Sets or queries the value used as the low reference level of the rising edge.
MEASUrement:REFLevels:ABSolute:RISEMid Sets or queries the value used as the mid reference level of the rising edge.
MEASUrement:REFLevels:ABSolute:TYPE Sets or queries the reference level type.
MEASUrement:REFLevels:BASETop Sets or queries the method used to calculate the TOP and BASE, used to calculate
reference levels.
MEASUrement:REFLevels:JITTERMODE Sets or queries how often reference levels are calculated on Jitter measurements.
MEASUrement:REFLevels:METHod Sets or queries the method used to calculate reference levels.
MEASUrement:REFLevels:MODE This command sets or queries how often reference levels are calculated.
MEASUrement:REFLevels:PERCent:FALLHigh Sets or queries the percentage used to calculate the high reference level of the falling
edge.
MEASUrement:REFLevels:PERCent:FALLLow Sets or queries the percentage used to calculate the mid reference level of the falling
edge.
MEASUrement:REFLevels:PERCent:FALLMid Sets or queries the percentage used to calculate the mid reference level of the falling
edge.
MEASUrement:REFLevels:PERCent:
HYSTeresis
Sets or queries the percentage used to calculate the hysteresis of the reference level.
MEASUrement:REFLevels:PERCent:RISEHigh Sets or queries the percentage used to calculate the high reference level of the rising
edge.
MEASUrement:REFLevels:PERCent:RISELow Sets or queries the percentage used to calculate the low reference level of the rising
edge.
2-50 MSO54, MSO56, MSO58, MSO58LP Programmer
