Command groups
Table 2-37: Search and Mark commands (cont.)
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:IPHeader:DESTinationaddr:
VALue
Specifies the 32-bit value to use when searching on the Ethernet IPv4 header
address destination field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:IPHeader:PROTOcol:VALue
Specifies the 8-bit value to use when searching on the Ethernet IPv4 header
protocol field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:IPHeader:SOUrceaddr:VALue
Specifies the 32-bit value to use when searching on the Ethernet IPv4 header
address source field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:MAC:ADDRess:DESTination:
VALue
Specifies the 48-bit value to use when searching on the Ethernet MAC address
destination field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:MAC:ADDRess:SOUrce:VA Lue
Specifies the 48-bit value to use when searching on the Ethernet MAC address
source field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:MAC:LENgth:HIVALue
Specifies the 16-bit high value to use when searching on the Ethernet MAC
length/type.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:MAC:LENgth:VALue
Specifies the 16-bit value to use when searching on the Ethernet MAC length/type.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:QTAG:VALue
Specifies the 32-bit value to use when searching on the Ethernet Q-Tag field.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:TCPHeader:ACKnum:VALue
Specifies the 32-bit value to use when searching on the Ethernet TCP header
acknowledgement number.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:TCPHeader:DESTinationport:
VALue
Specifies the 16-bit value to use when searching on the Ethernet TCP header
destination port number.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:TCPHeader:SEQnum:VALue
Specifies the 32-bit value to use when searching on the Ethernet TCP header
sequence number.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
ETHERnet:TCPHeader:SOUrceport:VALue
Specifies the 16-bit value to use when searching on the Ethernet TCP header
source port number.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
FLEXRAY:CONDition
Sets or queries FlexRay bus search trigger condition.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
FLEXRAY:CYCLEcount:VALue
Sets or queries the FlexRay bus search cycle count value.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
FLEXRAY:DATa:VALue
Sets or queries the FlexRay bus search cycle count value.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
FLEXRAY:CYCLEcount:HIVALue
Sets or queries the FlexRay bus search cycle count value.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
FLEXRAY:CYCLEcount:QUALifier
Sets or queries the FlexRay bus search trigger cycle count qualifier.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
FLEXRAY:DATa:HIVALue
Sets or queries the FlexRay bus search trigger data value.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
FLEXRAY:DATa:OFFSet
Sets or queries the FlexRay bus search trigger data offset.
2-66 MSO54, MSO56, MSO58, MSO58LP Programmer
