Tektronix MSO56 User Manual

Command groups
Table 2-37: Search and Mark commands (cont.)
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:BUS:
MIL1553B:STATus:BIT:SRQ
Sets or queries the value of the status word service request bit (SRQ bit, bit 11) in
a status word for a MIL-STD-1553 bus to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
MIL1553B:STATus:BIT:BCR
Sets or queries the value of the broadcast command received bit (BCR bit, bit 15) in
a status word for a MIL-STD-1553 bus to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
MIL1553B:STATus:BIT:BUSY
Sets or queries the value of the busy bit (BUSY bit, b it 16) in a status word for a
MIL-STD-1553 bus to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
MIL1553B:STATus:BIT:SUBSF
Ssets or queries the value of the subsystem flag bit (SUBSF bit, bit 17) in a status
word for a MIL-STD-1553 bus to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
MIL1553B:STATus:BIT:DBCA
Sets or queries the value of the dynamic bus control acceptance bit (DBCA bit, bit
18) in a status word for a MIL-STD-1553 bus to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
MIL1553B:STATus:BIT:TF
Sets or queries the value of the terminal flag bit (TF bit, bit 19) in a status word
for a MIL-STD-1553 bus to search on.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
PARallel:DATa:VALue
Sets or queries the data value for a parallel bus trigger search to determine where
to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
RS232C:DATa:VALue
Sets or queries the data string value for the specified RS232c bus trigger search to
determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
RS232C:CONDition
Sets or queries the condition for an RS232C bus search to determine where to
place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
RS232C:DATa:SIZe
Sets or queries the length of the data string in bytes to be used for an RS232 bus
search to determine where to place a mark when the search condition is Data.
SEARCH:SEARCH<x>:TRIGger:A:BUS:
SOUrce
Sets or queries the bus source for the specified bus trigger search to determine
wheretoplaceamark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:S PI:
CONDition
Sets or queries the trigger condition for the specified SPI bus trigger search to
determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:S PI:
DATa:SIZe
Sets or queries the length of the data string in bytes used for the specified SPI bus
trigger search to determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:S PI:
DATa:VALue
Sets or queries the data value of the data token for the specified SPI bus trigger
search to determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:USB:
ADDress:HIVALue
Sets or queries the address value for normal token to be used with In Range and
Out of Range qualifiers for the specified USB bus trigger search to determine
wheretoplaceamark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:USB:
ADDress:VALue
Sets or queries the address value for normal token for the specified USB bus trigger
search to determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:USB:
CONDition
Sets or queries the search condition for the specified USB bus trigger search to
determine where to place a mark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:USB:
DATa:HIVALue
Sets or queries the data value for data token used with In Range and Out of Range
qualifiers for the specified USB bus trigger search to determine where to place
amark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:USB:
DATa:OFFSet
Sets or queries data offset for the specified USB bus trigger search to determine
wheretoplaceamark.
SEARCH:SEARCH<x>:TRIGger:A:BUS:USB:
DATa:SIZe
Sets or queries the length of the data string in bytes for the specified USB bus
trigger search to determine where to place a mark.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-69
