Command groups
Table 2-40: Trigger commands (cont.)
Command
Description
TRIGger:{A|B}:BUS:B<x>:USB:DATa:
QUALifier
Sets the qualifier to be used when triggering on a USB bus signal.
TRIGger:{A|B}:BUS:B<x>:USB:DATa:SIZe Specifies the number of contiguous data bytes to trigger on.
TRIGger:{A|B}:BUS:B<x>:USB:DATa:TYPe Specifies the data type for when the trigger condition is set to DATAP acket.
TRIGger:{A|B}:BUS:B<x>:USB:DATa:VALue Specifies the binary data string to be u sed for the U SB trigger when the trigger
condition is DATAPacket.
TRIGger:{A|B}:BUS:B<x>:USB:ENDPoint:
VALue
Specifies the binary endpoint string to be used for the USB trigger.
TRIGger:{A|B}:BUS:B<x>:USB:ERRType Specifies the error type to be used when the trigger condition is set to ERRor.
TRIGger:{A|B}:BUS:B<x>:USB:
HANDSHAKEType
Specifies the handshake type for the USB trigger.
TRIGger:{A|B}:BUS:B<x>:USB:
SOFFRAME NU M ber
Specifies the binary data string to be used for start of frame number, when the trigger
condition is Token Packet and the token type is Start of Frame.
TRIGger:{A|B}:BUS:B<x>:USB:
SPECIALType
Specifies the packet ID (PID) for the special packet.
TRIGger:{A|B}:BUS:B<x>:USB:SPLit:ET:
VALue
When triggering on a high-speed USB split transaction, this command specifies the
split transaction endpoint type value to trigger on.
TRIGger:{A|B}:BUS:B<x>:USB:SPLit:HUB:
VALue
When triggering on a high-speed USB split transaction, this command specifies the
split transaction hub address value to trigger on.
TRIGger:{A|B}:BUS:B<x>:USB:SPLit:PORT:
VALue
When triggering on a high-speed USB split transaction, this command specifies the
split transaction port address value to trigger on.
TRIGger:{A|B}:BUS:B<x>:USB:SPLit:SC:
VALue
When triggering on a high-speed USB split transaction, this command specifies
whether to trigger on the start or complete phase of the split transaction, based on
the Start/Complete bit field value.
TRIGger:{A|B}:BUS:B<x>:USB:SPLit:SE:
VALue
When triggering on a high-speed USB split transaction, this command specifies the
split transaction start/end bit value to trigger on.
TRIGger:{A|B}:BUS:B<x>:USB:TOKENType Specifies the token type for the USB trigger.
TRIGger:{A|B}:BUS:SOUrc e Sets or queries the source for a bus trigger.
TRIGger:{A|B}:EDGE:COUPling S ets or queries the type of coupling for the edge trigger.
TRIGger:{A|B}:EDGE:SLOpe S ets or queries the slope for the edge trigger.
TRIGger:{A|B}:EDGE:SOUrce Sets or queries the source for the edge trigger.
TRIGger:{A|B}:LEVel:CH<x> Sets or queries the level for the trigger for the channel.
TRIGger:{A|B}:LOGIc:DELTatime Specifies or queries the Logic trigger delta time value.
TRIGger:{A|B}:LOGIc:FUNCtion Sets or queries the logical combination of the input channels for the logic trigger.
TRIGger:{A|B}:LOGIc:INPut:CLOCk:SOUrce Specifies the channel to use as the clock source.
TRIGger:{A|B}:LOGIc:POLarity Sets or queries the polarity for the clock channel when Use Clock Edge is set to
Yes for Logic trigger type.
TRIGger:{A|B}:LOGIc:USECLockedge Sets whether or not Logic trigger type uses clock s ource.
TRIGger:{A|B}:LOGIc:WHEn Sets or queries the condition for generating a logic trigger with respect to the defined
input pattern.
2-82 MSO54, MSO56, MSO58, MSO58LP Programmer
