Command groups
Table 2-40: Trigger commands (cont.)
Command
Description
TRIGger:{A|B}:BUS:B<x>:MIL1553B:
STATus:BIT:INSTR
Sets or queries the value of the instrumentation bit (INSTR bit, bit 10) in a status
word for a MIL-STD-1553 bus to triggering on.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:
STATus:BIT:SRQ
Sets or queries the value of the status word service r equest b it (SRQ bit, bit 11) in a
status word for a MIL-STD-1553 bus to triggering on.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:
STATus:BIT:BCR
Sets or queries the value of the broadcast command received bit (BCR bit, bit 15) in
a status word for a MIL-STD-1553 bus to triggering on.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:
STATus:BIT:BUSY
Sets or queries the value of the busy bit (BUSY bit, bit 16) in a status word for a
MIL-STD-1553 bus to triggering on.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:
STATus:BIT:SUBSF
Sets or queries the value of the subsystem flag bit (SUBSF bit, bit 17) in a status
word for a MIL-STD-1553 bus to triggering on.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:
STATus:BIT:DBCA
Sets or queries the value of the dynamic bus control acceptance bit (DBCA b it, bit
18) in a status word for a MIL-STD-1553 bus to triggering on.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:
STATus:BIT:TF
Sets or queries the value of the terminal flag bit (TF bit, bit 19) in a status word for
a MIL-STD-1553 bus to triggering on.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:TIMe:
QUALifier
Sets or queries the qualifier to be used when triggering on response time / inter
message gap time for a MIL-STD-1553 bus.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:TIMe:
LESSLimit
Sets or queries the lower limit to be used when triggering on response time / inter
message gap time for a MIL-STD-1553 bus.
TRIGger:{A|B}:BUS:B<x>:MIL1553B:TIMe:
MORELimit
Sets or queries the upper limit to be used when triggering on response time / inter
message gap time for a MIL-STD-1553 bus.
TRIGger:{A|B}:BUS:B<x>:PARallel:DATa:
VALue
Specifies the binary data string used for a Parallel Bus trigger.
TRIGger:{A|B}:BUS:B<x>:RS232C:
CONDition
Specifies the condition for an RS-232C trigger.
TRIGger:{A|B}:BUS:B<x>:RS232C:DATa:
SIZe
Sets or queries the length of the data string in bytes to be used for an RS232 trigger.
TRIGger:{A|B}:BUS:B<x>:RS232C:DATa:
VALue
Sets or queries the data value of the data token for an RS232 trigger.
TRIGger:{A|B}:BUS:B <x >:SPI:C ONDition Specifies the trigger condition for a SPI trigger.
TRIGger:{A|B}:BUS:B <x>:SPI:DATa:SIZe Specifies the length of the data string to be used for a SP I trigger if the trigger
condition is DATa.
TRIGger:{A|B}:BUS:B<x>:SPI:DATa:VALue Specifies the binary data string used for SP I triggering if the trigger condition is DATA .
TRIGger:{A|B}:BUS:B<x>:USB:ADDRess:
HIVALue
Specifies the binary address string for the upper limit for inside-of-range and
outside-of-range qualifiers for the USB trigger.
TRIGger:{A|B}:BUS:B<x>:USB:ADDRess:
VALue
Specifies the binary address string to be used for USB trigger.
TRIGger:{A|B}:BUS:B <x>:USB:CONDition Specifies the trigger condition for the USB trigger.
TRIGger:{A|B}:BUS:B <x>:USB:DATa:
HIVALue
Specifies the binary data string for the upper limit for inside-of-range and
outside-of-range qualifiers for the USB trigger when the trigger condition is
DATAPacket.
TRIGger:{A|B}:BUS:B <x>:USB:DATa:
OFFSet
Specifies the data offset in bytes to trigger on.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-81
