X35 Monitor Air Seeder Setup
6.56
6.7.2.3.1 Proportional Valve Settings
1. Flow Meter Sampling - the default setting is
"Standard".
a. The optional "Reduced" sensitivity setting
slows the reaction time of the proportional
valve.
i. This
may be required for very low
flow rates, or if flow is highly
irregular or worn equipment.
2. Minimum/Maximum PWM
- are the limits of
the PWM (Pulse Width Modulation) drive and
they vary with the type of drive.
a. Min PWM - is a percentage of voltage
drive
to the coil.
b. Max PWM - is a percentage of voltage
drive
to the coil.
Figure 6.75 - Proportional Valve Settings
3. Controller Response - this will adjust how
fast the controller will respond to changes.
a. The default is set to "Fastest".
4. Dump
Valve - is used to apply a signal to a
dump
valve or master valve.
a. Enabled - applies power when tank is off.
b. Reversed - applies power when tank is on.
