X35 Console System Components
1.5
1.4.2 Power Extension Harness
Power extension harness connects X35 console to
the power source.
There are two power extension harnesses available:
1. One, with the auxiliary connector, to connect
in the cab (3151-69, refer to Figure 1.7).
2.
The other, has leads to connect to the battery
and switched power source (3151-68, refer to
Figure 1.8).
Figure 1.8 - Power Extension Harness (3151-68)
Figure 1.7 - Power Extension Harness (3151-69)
1.4.3 Tractor ISOBUS Harness
The tractor ISOBUS harness connects to the
battery and tees into the X35 harness. The
implement plugs into the harness at back of the
tractor.
Figure 1.9 - Bourgault ISOBUS X35 Harness
(3151-78)
