X35 Monitor Air Seeder Setup
6.58
Figure 6.77 - NH3 Flow Settings
9. PWM Setting - is the Pulse Width
Modulation.
a. Lowering
this number reduces the voltage
supplied to the valve, slowing it down.
Important
These different valve models have their own
default presets loaded.
If you have fluctuating NH3 rates, it is best to
start adjustments with the GAIN setting first, then
adjust the MIN/MAX times. Adjust the PWM
settings last.
6.7.2.4 Pressure Settings
Pressure sensor is selected if there is an electric
pressure sensor in the product line (not supported
through Bourgault Harnessing).
1. Sensor - default is set to None.
a.
If
set to Voltage, additional settings that
need to be configured will appear.
