X35 Console General Operations
8.5
Figure 8.7 - Tank Fill Panel
8.2 Filling the Tank
Figure 8.6 - Entering Weight
Enter
Weight
Button
A
B
C
D E F
G
H
When the air seeder, NH3 or Liquid tanks
are filled or refilled, the tank levels will not
automatically reset to full.
Once filling is complete:
1. In the Seeder Controller window (full screen
mode);
a.
Display the "Tank" that you would like to
enter a weight for.
b. Expand the panel for that tank.
c. Refer to Figure 8.6.
2.
Select the Weight button, the tank fill panel
will appear, refer to Figure 8.7.
a.
The title block (Item A, Figure 8.7)
displays
the name of the tank (Bin # or
Tank #, product name or empty, or custom
name) depending on the settings, refer to
Section 6.7.1 - Granular Setup and 6.7.2
- NH3/Liquid Setup.
3. Fill the tank using the functions of the tank fill
panel,
refer to Figure 8.7:
a. Known
Weight (Item B, Figure 8.7)
i.
The Exact weight of the product in
the tank can be determined during the
fill, using the air seeder tank weigh
system or if using bagged product,
with the weight stated on each bag.
b. Weight Increment (Item C, Figure 8.7)
i.
Enter a weight value that will be
used when increasing weight in the
tank by increments.
ii. If there was product remaining in
the tank before filling, you can enter
a new value from the weigh system
and then add it to existing value.
iii. Alternatively, if adding canola bags
or a known weight, enter it here and
press the button "Increase weight by
increment" (Item E Figure 8.7) for
how
many bags are being added.
