Topcon X35 - Configure Job Regions

X35 ConsoleField / Job
9.16
9.3.3 Configure Job Regions
This section allows you to set how Categorized
Field Boundary Regions are handled for the
current job.
A boundary needs to be assigned as a Categorized
Region in order for this option to show up
under the Job menu, refer to Section 9.2.5.2
-
Manipulating Field Boundaries to categorize
boundaries
Open the Job Menu
and select
Configure Job Regions. This will open the Job
Regions Menu, refer to Figure 9.24.
1. W
ork Regions - pick groups of Boundaries
you would like to apply as Work Regions for
the current job.
a. Selected boundaries will be highlighted.
b. Product will be applied within boundaries.
Figure 9.24 - Job Regions Menu
2. Excluded Regions - pick groups of boundaries
you would like to handle as Excluded Regions
for the current job.
a. Selected boundaries will be highlighted.
b. Product will not be applied within these
boundaries.
Note
Any Categorized Regions that are not selected
in this window will be treated as disabled regions
and ignored for the current Job.
Water
Dried Up Slough
Headland
Field
Boundary
