X35 ConsoleTroubleshooting
12.2
SYMPTOM PROBABLE CAUSE SOLUTION
Monitor will not
power up.
Low voltage. Start vehicle - check battery voltage.
Blown fuse. Check for damaged wiring.
Damaged unit.
Contact Bourgault dealer for repair and/or
replacement.
Blank
display after
startup.
Damaged
unit. Contact Bourgault dealer.
Error messages on
startup.
Missing
or corrupt files. Contact Bourgault dealer.
White Screen Frozen screen. Contact Bourgault dealer.
No power to ECU's on
the tank.
(No LED's lit up)
No implement power. Recycle tractor key.
Blown fuse. Check 100A fuse near tractor battery.
Poor connection.
Check connection at the tractor, rear of the drill
and connections into the ECU(s).
12.1 Start-Up
12.2 Controls
SYMPTOM PROBABLE CAUSE SOLUTION
Touch screen control buttons
will not work.
Virtual switches not
enabled.
In
Setup screen go to Implement/Operator Input
(refer to Section 6.8 - Operator Inputs).
In-cab keypad controls will
not work.
Keypad switches not
enabled.
In
Setup screen go to Implement/Operator Inputs
(refer to Section 6.8 - Operator Inputs).
In-cab or tank mounted
keypad flashing.
Not set up.
Assign keypads. In Setup screen go to
Implement/Operator Inputs. Refer to Section
6.8.2
- Keypad.
Not synchronized. Unplug keypad and reconnect.
No LEDs on keypad.
Brightness not
adjusted.
Adjust
brightness of X35 monitor.
Some LEDs are out on
keypads.
Not
synchronized. Restart X35 console/tractor to reboot system.
