Topcon X35 - Accessories; Sensor Setup

X35 Monitor Air Seeder Setup
6.65
6.7.6 Accessories
The accessories menu will allow you to set up
features such as sensors, blockage monitoring
system and granular section monitoring.
6.7.6.1 Sensor Setup
Select Implement/Seeder/Accessories/Sensor Setup.
1. Depending on the configuration of the seeding
system, if it has granular ASC, NH3/Liquid
ASC and/or blockage monitoring, air seeders
can have up to three EM-24 ECU’s.
Figure 6.83 - Accessories Menu
2. Sensor types for these ECU’s depend on what
they are controlling. These are preset from
the factory profiles so would only need to be
modified for a custom profile.
a. If the EM-24 ECU is used for section
control the sensors need be set to
"Granular Section Sense".
b. If the EM-24 ECU is used for blockage
monitoring the sensors need to be set to
"Blocked Head Sense".
c. Press on the cell marked, to change all
the sensor types at once for that particular
EM-24.
