Topcon X35 - 7000;8000;9000 Series Air Seeders

X35 Console General Operations
8.15
8.4.2.1 7000/8000/9000 Series Air Seeders
1. On the Calibration Method window, refer to
Figure 8.25, select Automatic Calibration.
a.
The Granular calibration wizard will start
up, refer to Figure 8.26.
b.
Select the yellow arrow to proceed to the
next step.
Figure 8.25 - Calibration Method Window
Figure 8.27 - Calibration Wizard - Screen 2/4
Figure 8.26 - Calibration Wizard
Note
Ensure that displayed manual speed is the same
as the planned seeding speed. Refer to Figure
8.27.
2. Engage the hydraulic power to the Fan 1
circuit. For additional instructions on this
procedure, refer to your Air Seeder manual.
Confirm Speed
