Topcon X35 - Clearing a Job; Variable Rate Control

X35 Console Field / Job
9.19
9.3.7 Variable Rate Control
If the Variable Rate Control (VRC) has been
enabled (refer to Section 4.2.4 - Implement), select
. Configure the VRC on the Job Menu to
start the VRC wizard (Figure 9.28).
1. Pick a VRC file format.
a. Select from the Shape files (most common)
and ISO XML.
b. Note that these file types are different from
the XML file type that was used with the
X20 Monitor. Refer to Figure 9.29.
Figure 9.28 - VRC Wizard - Step 1
Figure 9.29 - VRC Wizard - Step 2
9.3.6 Clearing a Job
This action will remove any coverage information
on the screen and delete the job data that has been
recorded on the current job. It does not affect the
field information or guidelines set for the field. It
will clear the job area counters depending on the
setting for resetting job area counters. Refer to
Section 4.2.4 - Implement.
1. To clear the Job Data select
from the
Job Menu and confirm.
