X35 Console Monitoring & Managing Files
10.11
Figure 10.22 - System Information Panel
10.6 System information
Figure 10.21 - About Mini-View Window
Scroll
Bar
Select the icon to open the About mini-view
window. Refer to Figure 10.21.
The About window displays date, time, and the
current
version of the software.
1. Selecting the Maximize Arrow (top right
corner) will expand mini-view window into
main viewing area.
2. The information displayed in the full System
Information panel is divided in to five sections:
a. Console
b. GPS Receiver
c. Steering Controller
d. Implement
e. Wireless Network
i. Use arrows in the Sections Title bar
to expand or hide.
ii. When needed a scroll bar will be
displayed. Refer to Figure 10.22.
Maximize
Arrow
To Next Page
