X35 ConsoleOverview
2.12
Refer to Figure 2.17.
This is the Seeder Controller Icon, located
in mini-view menu. Selecting this icon
will open Seeder Controller mini-view
window.
1. The Seeder Controller mini-view window can
be expanded into a main screen.
a. To expand the Seeder Controller select
the top right maximize arrow or touch the
mini-view window and slide towards the
main screen, refer to Figure 2.18.
The
Seeder Controller in full screen mode provides
extra functions like selecting product, filling tank,
calibration and etc., that are not available in mini-
view window.
2. The Seeder Controller can be viewed in both
modes at the same time.
a. While the Seeder Controller is in the full
screen mode, select the Seeder Controller
icon from the mini-view menu again, and
the secondary Seeder Controller mini-view
window will open again, refer to Figure
2.19.
3.
The purpose of this window is to allow an
operator to have a secondary view of the air
seeder functions and controls.
a. For instance, you can set the full screen to
show four granular tanks and on the mini-
view select the NH3 tab for viewing, or;
b. You may want to set the mini-view
tank tabs to display different parameters
compared to a tank panel in full screen
mode.
2.6 Seeder Controller
Figure 2.17 - Seeder Controller Mini-View
Expand
Touch the mini-view and slide
towards the main screen to expand
Figure 2.18 - Seeder Controller in Full Screen Mode
Figure 2.19 - Seeder Controller - Full Screen Mode &
Mini-View
